Multi-blade Cutting Machine

• Place of Origin:

   China

• Type:

  Quarrying and Earthmoving Machinery

• Genre:

  Machinery & Equipment

• sCode:

  STPR1276262

• Place of Origin:

  China
•
  Structure and Features
         Suspension-type structure is adopted for old Multi-blade Cutting Machine. The rotating, feeding, and retrieving of the machine's blades as well as the bldily horizontal movement of the trolley are centrally controlled from an electric control unit. It has high automation level, with excellent machining ability, stable performance as well as high efficiency and low energy consumption.
         GQJ-160 Large-scale Stone Cutting Machine adopts a forward protrusion frame structure. It's widely used for the processing of granite and marble thin plate. It's stable and highly-efficient.


  Technical data:
  Item No.: TGQ-160-9 / TGO-160-12
  Max. No. of blade:  9 (3-1600mm ,3- 1150mm ,3- 690mm) / 12 (6- 1600mm, 6- 940mm)
  Blade vertical stroke: 1000 mm
  Max. Cutting size: 3500 x 1300 x 650 mm
  Power of main motor: 45 / 55 kw
  Water consumption: 16 M3/H
  Dimension: 8500 x 4000 x 5500 mm
  Weight: 8500 kgs
